Spectrum Chart
Rhodamine 6G Spectrum
| Excitation (㎚) | Emission (㎚) |
| 570 | 590 |
Recommended Filter
-
일반 형광 Lighting source 사용시
| Filter Model No. | Excitation filter (㎚) | Dichroic mirror (㎚) | Emission filter (㎚) | Remarks |
| 49023 | 480/40 (460~500) |
510 (LP) | 535/50 (510~560) |
Wide Excitation band, Bandpass Emission |
-
레이저 Lighting source 사용시
| Filter Model No. | Excitation filter (㎚) | Dichroic mirror (㎚) | Emission filter (㎚) | Remarks |
| 49906 | 514/10 (509~519) |
514 (LP) | 570/50 (545~595) |
For use with laser between 511~517㎚
Narrow Excitation band, |
| 49907 | 532/10 (527~537) |
532 (LP) | 575/50 (550~600) |
For use with laser between 529~535㎚
Narrow Excitation band, |
