Camera, Fluorescence

AcquCAM Pro/G3

AcquCAM Pro/G3

Down load Catalog _ AcquCAM PRO/G3

AcquCAM Pro/G3



 AcquCAM Pro/G3 USB 3.0 camera is the perfect solution for many bio, industrial, medical applications. Utilizing the very sensitive color CCD sensors, these cameras feature a specialization of fluorescence observations. With up to 30 fps and a trigger delay of less than 5 micro seconds.

  • 1.2 Mega pixel CCD camera
  • Color, Progressive scan
  • Preview software provided (JNOPTIC Capture)
  • Software compatible with Windows XP/ Vista/ 7/ 8 operating systems



LIVE PSEUDO COLOR

Ex. of applied PSEUDO COLOR for black live fluorescence image



Emphasis function on variety of images

AcquCAM Pro G3_15
With emphasis function, BLACK BALANCE / AUTO LEVEL of ARM on variety images, you could acquire cleaner and sharper images.



Acquiring high sensitive images

These images were shot by AcquCAM Silver Package.
These images were shot by AcquCAM Silver Package.



Acquiring high sensitive images from general lighting source

[Specification]
Spec Description
Size 1/3 inch
Resolution H: 1280, V: 960
Pixel size H: 3.75 µm, V: 3.75 µm
Video formats

& Frame rate

 1280×960 RGB32 @ 30, 20, 15, 7.5, 3.75 fps

1280×960 Y800 @ 30, 20, 15, 7.5, 3.75 fps

1280×960 Y16 @ 30, 20, 15, 7.5, 3.75 fps
Sensitivity 0.05 lx
Exposure time 1/10000 to 30 s
Lens mount C/Cs mount
Interface USB 3.0
Power supply 4.5 to 5.5 VDC
Dimensions H: 29 mm, W: 29 mm, L: 43 mm
Mass 65 g
